[NVIDIA] 젯슨 Gstreamer RTSP 자료 모음

Jetson에서 지원하는 Gstreamer 실시간 스트리밍 프로토콜(RTSP) 테스트



videotestsrc



'videotestsrc is-live=true ! '
'video/x-raw, width=1920, height=1080, framerate=30/1, format=UYVY ! '
'timeoverlay halignment=right valignment=bottom text="Stream time:" shaded-background=true font-desc="Sans, 24" ! '
'nvvidconv ! nvv4l2h264enc ! rtph264pay name=pay0 pt=96'



디바이스 연결만 H.265는 N개 클라이언트 접속 가능한데 H.264는 안되는 이슈 발생 (나중에 확인할 예정)



display-name=:0

'ximagesrc display-name=:0 use-damage=0 ! '
'video/x-raw,framerate=30/1 ! '
'videoconvert ! '
'x264enc tune=zerolatency speed-preset=ultrafast bitrate=1500 ! '
'timeoverlay halignment=right valignment=bottom text="Stream time:" shaded-background=true font-desc="Sans, 24" ! '
'clockoverlay halignment=left valignment=top shaded-background=true font-desc="Sans, 24" ! '
'rtph264pay config-interval=1 name=pay0 pt=96'





---

참조사이트



https://github.com/GStreamer/gst-rtsp-server

GitHub - GStreamer/gst-rtsp-server: RTSP server based on GStreamer. This module has been merged into the main GStreamer repo for



https://docs.nvidia.com/jetson/archives/r34.1/DeveloperGuide/text/SD/Multimedia/AcceleratedGstreamer.html

Accelerated GStreamer — Jetson Linux<br/>Developer Guide 34.1 documentation



https://forums.developer.nvidia.com/t/nvmm-memory/50217/4

NVMM memory



https://gist.github.com/liviaerxin/bb34725037fd04afa76ef9252c2ee875

GStreamer Pipeline Samples #GStreamer
